Practical overview
When it fits
Use Archify when you want a compatible AI agent to turn a written description, plan or codebase into an interactive HTML visual, especially when a repository-backed architecture map or iterative prompt-based refinement is useful.
Who it is for
- Developers who want an AI agent to map a repository’s runtime architecture.
- People turning a described system or workflow into an interactive visual.
- Learners and planners who want maps of topics, study plans or itineraries.
Documented uses
- Create an interactive architecture diagram from a system description or codebase.
- Turn a plan or topic into a navigable visual map.
- Refine a generated diagram through follow-up requests, such as emphasizing a path or changing its theme.
Requirements & limits
The project describes itself as free and open source. Third-party online services and paid plans mentioned by the project are operated by their respective providers.
- Archify is an agent skill, so the workflow depends on using a compatible AI-agent environment rather than a standalone editor.
- Documented agent contexts include Claude Code, Codex CLI, Cursor and OpenCode; installation steps vary by surface.
- Claude.ai support depends on Node.js access in its sandbox; Project Knowledge is described as a prompt-driven architecture fallback.
- Automatic Mermaid parsing, general-purpose auto-layout, hosted sharing and WYSIWYG editing are outside the documented scope.
Check current requirements in the official documentation. Source-based guidance does not mean OpenViST has run or independently tested this project.
Install Archify and request a diagram from a description
Install the Archify skill for a compatible AI agent and ask it to create an interactive diagram from a plain-language description.
Before you start
- A compatible agent such as Claude Code, Codex, Cursor, or OpenCode.
- Access to run the documented
npxinstallation command.
Steps
Install Archify globally with the command below.
npx skills add tt-a1i/archify -gIn your agent, describe the subject you want diagrammed and ask it to use Archify; for example, describe a browser-to-API request that checks Redis and falls back to PostgreSQL.
Review the generated diagram and ask the agent for supported changes, such as highlighting a path or switching the theme.
Expected outcome
The agent produces an interactive HTML diagram that can be explored, customized, and shared.
Guide limitations
- A repository is not required for a diagram based on a description; source-backed diagrams require asking the agent to inspect a repository.
- Archify does not automatically install updates; you choose whether and when to update.
Start a diagram from a bounded system overview
Use Archify to create a high-level architecture diagram from a plain-language system description without providing a repository.
Before you start
- An agent that can use the Archify skill.
- A system description covering users, core components, the primary path, external dependencies, and boundaries.
Steps
Install the Archify skill using the global installation command: the command below.
npx -y skills add tt-a1i/archify --skill archify --agent codex --global --copy --yesAsk Archify to turn the description into a high-level architecture diagram, keeping one primary path across 8–12 core components.
Ask for clarification on missing facts that would materially change the diagram, and have remaining unknowns marked rather than invented.
Expected outcome
A high-level architecture diagram organized around one primary path, with external dependencies and boundaries represented.
Guide limitations
- This recipe describes a diagram from a plain-language description; use a repository when source evidence matters.
- The recommended scope is 8–12 core components and one primary path.
